| Ask Lasest Price | |
| Brand Name : | Sdlg |
| Model Number : | E660FL |
| Certification : | SGS |
| Price : | $32000 |
| Payment Terms : | L/C, D/A, D/P, T/T |
| Supply Ability : | negotiable |
| Delivery Time : | 8 work days |
| Overall dimension | |
| Overall width of upper assembly(A) | 1870mm |
| Overall width(B) | 1960mm |
| Overall height of cab(C) | 2620mm |
| Tail swing radius(D) | 1670mm |
| Overall height of engine hood(E) | 1700mm |
| Ground clearance of counterweight (F) | 740mm |
| Wheelbase (G) | 1990mm |
| Crawler length (H) | 2540mm |
| Crawler gauge (I) | 1540mm |
| Crawler pad width (J) | 400mm |
| Min. ground clearance (K) | 367mm |
| Overall length (L) | 5930mm |
| Overall height of boom (M) | 1820mm |
| Overall parameters | |
| Bucket capacity | 0.21m³ |
| Overall operating weight | 6050kg |
| Max. excavation force | 45KN |
| Slew speed | 0-11.5r/min |
| Traveling speed (low/high) | 2.2/4.8km/h |
| Average ground pressure | 32kPa |
| Max. digging radius | 5990mm |
| Max. digging depth | 3846mm |
| Max. digging height | 5743mm |
| Max. dumping height | 4163mm |
| Min. front slewing radius | 2321mm |
| Engine | |
| Model | 4TNV98-EXSLGC |
| Type | Water-cooled, Four-stroke,Direct injection |
| Rated Power@Revolution Speed | 38.3kw/2200r/min |
| Displacement | 3319mL |
| Cylinder bore × stroke | 98×110mm |
| Emission standard | GB20891-2014 China Phase III |
| Rated fuel consumption | 238g/kw.h |
| Max. torque | 191.8-208.6N.m |
| Traveling/swing system | |
| Qty. of carrier rollers (single side) | 1 |
| Qty. of track rollers (single side) | 5 |
| Traveling brake type | Wet disc brake |
| Swing mode | Hydraulic drive internal tooth single-row ball-bearing |
| Swing brake type | Wet disc brake |
| Hydraulic system | |
| Hydraulic control type | Pilot proportional control valve |
| Hydraulic system type | constant power control system |
| Max. flow | 137L/min |
| Main pump model | HP3V80 |
| Operating pressure | 215kgf/cm2 |
| Main valve model | HVSE-12-08 |
| Arm cylinder - cylinder bore× diameter of piston rod × stroke | 1-90*55*816mm |
| Boom cylinder - cylinder bore× diameter of piston rod × stroke | 1-105*60*725mm |
| Bucket cylinder - cylinder bore× diameter of piston rod × stroke | 1-80*50*660mm |
| Fill capacity | |
| Fuel | 135L |
| Engine oil | 12L |
| Hydraulic oil | 157L |
| Antifreeze | 2×1.3L |
| Swing reducer | 1.2L |
|
|
